Stationary Scissor Lift Platform

The Stationary Scissor Lift Platform is a vertical lifting device that uses a scissor-type mechanical structure. It is mainly used for transporting goods between building floors, lifting cars between floors in multi-level parking garages and underground parking garages, and other similar scenarios.

Overview
Recommended Products

Product Information

Place of Origin	Shandong, China
Brand Name	wemet
Certification	CE/ISO
Applicable Industries	Building Material Shops, Farms, Home Use, Printing Shops, Hotels, Garment Shops
Customized Products	All equipment can be customized.

Product Business Terms

Minimum Order Quantity	Single item
Packaging Details	Wooden box
Delivery Time	15~45 days (To be negotiated)
Supply Ability	300 acres per Month

Description

1.Fully formed manganese steel hinge boom, uniform thickness.
2.H-shaped steel wide bottom enhances stability.
3.45 # carbon round steel finishing pin shaft, wear-resistant shaft bushing.
4.Overload triggers alarm and stops equipment operation.
5.Overload protection to prevent overload damage to the hydraulic system.
6.Emergency stop control button.
7.Emergency manual drop valve returns platform to lowest level.
8.With explosion-proof valve, oil cylinder can automatically maintain pressure after tubing burst.
9.Pressure feedback system, operation encountered jam, equipment automatically stop.
10.Fault self-diagnosis system. Fault code is automatically displayed for easy maintenance.

Quick Detail

1.Overload sound alarm
2.Pressure feedback system
3.Precision sealed cylinder
4.Fault self-diagnosis system
5.Explosion-proof valve
6.Emergency manual lowering valve
7.Overload protection
8.Emergency stop button

Applications
Stationary scissor lift platforms are widely used for:
• Transporting goods between different heights on production lines
• Adjusting the height of materials during loading and unloading, and during workpiece assembly
• Lifting components during the assembly of large equipment
• Rapid loading and unloading of goods in warehouses and storage areas in conjunction with forklifts and other handling vehicles
• Car lifting in automated parking systems and underground parking garages
• High-altitude operations in factories, warehouses, shopping malls, airports, and other similar locations

Specifications

Model	Platform Size（mm）	Load Capacity(kg)	Closed Height(mm)	Lifting Height(mm)	Weight(kg)	Motor Power(kw)
SJG1.0-1.0	1300*820	1000	205	1000	160	1.1
SJG1.0-1.3	1700*1000	1000	240	1300	210	1.1
SJG2.0-1.3	1700*1000	2000	250	1300	300	2.2
SJG2.0-1.3	2000*1000	2000	250	1300	315	2.2
SJG3.0-1.4	2200*1200	3000	300	1400	375	2.2
SJG4.0-1.4	2200*1200	4000	300	1400	505	2.2
SJG2.0-1.78	1300*850	2000	360	1780	235	1.5
SJG2.0-3.0	1700*1000	2000	560	3000	300	2.2

Support on-demand customization, the parameters are for reference only, please consult the WEMET Machinery Sales Department for details.

Advantages

**High Stability:** The scissor-type mechanical structure provides high stability after lifting. The large working platform and high load capacity make it suitable for multiple people to work simultaneously.
**High Safety:** The hydraulic system is equipped with anti-fall and overload safety protection devices. Operating buttons can be installed on each floor and on the platform itself, enabling multi-point control. It is equipped with safety railings, limit switches, and emergency stop buttons.
**Large Load Capacity:** Rated load capacity can reach several tons, meeting the needs for smoothly lifting heavy goods.
**Easy Operation:** Controlled by buttons or a remote control, operation is simple and convenient, and maintenance and use are flexible.
